Consul von HashiCorp bietet Service Discovery, Health Checking und Key-Value Storage. Es ist ideal für Microservices-Architekturen und dynamische Infrastrukturen.

Installation

# Binary herunterladen
wget https://releases.hashicorp.com/consul/1.17.1/consul_1.17.1_linux_amd64.zip
unzip consul_1.17.1_linux_amd64.zip
mv consul /usr/local/bin/

# Version prüfen
consul version

Development-Modus

# Schnellstart für Tests
consul agent -dev

# Web-UI: http://localhost:8500

Server-Konfiguration

Server-Konfig

# /etc/consul.d/server.hcl

datacenter = "dc1"
data_dir = "/var/lib/consul"
node_name = "consul-server-1"

server = true
bootstrap_expect = 3

bind_addr = "192.168.1.10"
client_addr = "0.0.0.0"

ui_config {
  enabled = true
}

# Cluster-Join
retry_join = ["192.168.1.10", "192.168.1.11", "192.168.1.12"]

# Verschlüsselung
encrypt = "ENCRYPTION_KEY"

Encryption-Key generieren

consul keygen
# Ausgabe in encrypt eintragen

Systemd-Service

# /etc/systemd/system/consul.service
[Unit]
Description=Consul Agent
After=network-online.target

[Service]
ExecStart=/usr/local/bin/consul agent -config-dir=/etc/consul.d/
ExecReload=/bin/kill -HUP $MAINPID
Restart=on-failure

[Install]
WantedBy=multi-user.target

Client-Konfiguration

# /etc/consul.d/client.hcl

datacenter = "dc1"
data_dir = "/var/lib/consul"
node_name = "web-server-1"

server = false
bind_addr = "192.168.1.20"

retry_join = ["192.168.1.10", "192.168.1.11", "192.168.1.12"]

encrypt = "ENCRYPTION_KEY"

Service Discovery

Service registrieren

# /etc/consul.d/web-service.hcl

service {
  name = "web"
  port = 80
  tags = ["production", "v1"]

  check {
    http = "http://localhost:80/health"
    interval = "10s"
    timeout = "2s"
  }
}

Über API registrieren

curl -X PUT http://localhost:8500/v1/agent/service/register -d '{
  "Name": "api",
  "Port": 8080,
  "Tags": ["production"],
  "Check": {
    "HTTP": "http://localhost:8080/health",
    "Interval": "10s"
  }
}'

Services abfragen

# Alle Services
consul catalog services

# Service-Details
consul catalog nodes -service=web

# Via API
curl http://localhost:8500/v1/catalog/service/web

DNS-Interface

# Service-Lookup
dig @127.0.0.1 -p 8600 web.service.consul

# Mit DC
dig @127.0.0.1 -p 8600 web.service.dc1.consul

# SRV-Records (mit Port)
dig @127.0.0.1 -p 8600 web.service.consul SRV

Health Checks

Check-Typen

# HTTP-Check
check {
  http = "http://localhost:8080/health"
  interval = "10s"
  timeout = "2s"
}

# TCP-Check
check {
  tcp = "localhost:3306"
  interval = "10s"
}

# Script-Check
check {
  args = ["/usr/local/bin/check-service.sh"]
  interval = "30s"
}

# TTL-Check (Service meldet sich)
check {
  ttl = "30s"
}

TTL-Check aktualisieren

# Status melden
curl -X PUT http://localhost:8500/v1/agent/check/pass/service:web
curl -X PUT http://localhost:8500/v1/agent/check/fail/service:web

Key-Value Store

CLI

# Schreiben
consul kv put config/database/host "db.example.de"
consul kv put config/database/port "5432"

# Lesen
consul kv get config/database/host

# Mit Prefix
consul kv get -recurse config/database/

# Löschen
consul kv delete config/database/host
consul kv delete -recurse config/database/

API

# Schreiben
curl -X PUT -d 'db.example.de' http://localhost:8500/v1/kv/config/database/host

# Lesen
curl http://localhost:8500/v1/kv/config/database/host
# Wert ist Base64-kodiert

# Dekodiert
curl http://localhost:8500/v1/kv/config/database/host?raw

Watch

# Auf Änderungen warten
consul watch -type=key -key=config/database/host cat

ACL (Access Control)

ACL aktivieren

# server.hcl
acl {
  enabled = true
  default_policy = "deny"
  enable_token_persistence = true
}

Bootstrap

consul acl bootstrap
# Gibt Bootstrap-Token aus - sicher aufbewahren!

Policies und Tokens

# Policy erstellen
consul acl policy create -name "read-config" -rules @policy.hcl

# Token erstellen
consul acl token create -policy-name="read-config"
# policy.hcl
key_prefix "config/" {
  policy = "read"
}

service_prefix "" {
  policy = "read"
}

Prepared Queries

# Query erstellen
curl -X POST http://localhost:8500/v1/query -d '{
  "Name": "healthy-web",
  "Service": {
    "Service": "web",
    "OnlyPassing": true
  }
}'

# Query ausführen
curl http://localhost:8500/v1/query/healthy-web/execute

# Via DNS
dig @127.0.0.1 -p 8600 healthy-web.query.consul

Consul Template

# Installation
wget https://releases.hashicorp.com/consul-template/0.35.0/consul-template_0.35.0_linux_amd64.zip
unzip consul-template_0.35.0_linux_amd64.zip
mv consul-template /usr/local/bin/

Template

# nginx.ctmpl
upstream backend {
{{range service "web"}}
    server {{.Address}}:{{.Port}};
{{end}}
}

server {
    listen 80;
    location / {
        proxy_pass http://backend;
    }
}

Ausführen

consul-template \
    -template "nginx.ctmpl:nginx.conf:nginx -s reload"

Backup und Restore

# Snapshot erstellen
consul snapshot save backup.snap

# Restore
consul snapshot restore backup.snap

Monitoring

# Cluster-Status
consul members

# Leader
consul operator raft list-peers

# Metriken
curl http://localhost:8500/v1/agent/metrics

Praktisches Beispiel

Load Balancer mit Consul Template

# /etc/consul-template/haproxy.ctmpl

backend web_backend
    balance roundrobin
{{range service "web"}}
    server {{.ID}} {{.Address}}:{{.Port}} check
{{end}}
consul-template \
    -template "/etc/consul-template/haproxy.ctmpl:/etc/haproxy/haproxy.cfg:systemctl reload haproxy"

Zusammenfassung

| Befehl | Funktion | |--------|----------| | consul agent | Agent starten | | consul members | Cluster-Status | | consul catalog services | Services auflisten | | consul kv put/get | Key-Value Operationen | | consul snapshot | Backup/Restore |

| Port | Verwendung | |------|------------| | 8500 | HTTP API | | 8600 | DNS | | 8301 | LAN Serf | | 8302 | WAN Serf | | 8300 | RPC |

| Konzept | Beschreibung | |---------|--------------| | Service | Registrierter Dienst | | Check | Health Check | | KV | Key-Value Store | | ACL | Zugriffskontrolle |

Fazit

Consul vereint Service Discovery und Konfiguration. Das DNS-Interface ermöglicht einfache Integration. Health Checks sorgen für Zuverlässigkeit. Consul Template automatisiert Konfigurationen. Für Kubernetes ist Consul via Helm Chart verfügbar.
